Star Trackers

Focusing on fully autonomous attitude determination with high accuracy

STAR TRACKERS FOR MISSIONS FROM LEO TO DEEP SPACE EXPLORATION

Our series of star trackers support space missions ranging from satellites with short mission lifetimes to satellites having long lifetimes and stringent requirements for radiation tolerance.

Autonomous high-accuracy attitude determination

Superior radiation resistance

Flight proven

T1 Star Tracker X2 White (1)
T1 Star Tracker

SUITABLE FOR HIGH RADIATION MISSIONS

The T1 Star Tracker is based on the sensor chip Faintstar-2 which is a CMOS Active Pixel Sensor with a suite of integrated on-chip functionality supporting a completely new class of miniaturized high performance star trackers. The T1 is built with Class 1 or 2 components and is suitable for high radiation missions, e.g., geostationary satellites with electrical orbit raising and 15 years in GEO. T1 has a separated baffle and camera for best thermal stability, and a separate data processing unit.
T1 Data Sheet
Star Tracker T3
T3 Star Tracker

SUITABLE FOR MICROSATELLITE MISSIONS

T3 is a very compact star tracker with high accuracy and excellent thermal stability ideally suited for microsatellite missions designed for a lifetime of 5 years in LEO.As a scaled-down version of the T1 Star Tracker, the T3 Star Tracker has a smaller optical system and computer processing unit that is based on highly reliable COTS components. The built-in processing unit in T3 Star Tracker accommodates the star catalogue and software algorithms for autonomous attitude acquisition and tracking.
T3 Data Sheet
OGSE S2 White Background
Dynamic Optical Ground Support Equipment (DOGSE)

OPTICAL GROUND SUPPORT FOR T1 AND T2

The Dynamic Ground Support Equipment (DOGSE), designed for T1 and T3 Star Trackers, offers a streamlined installation process and user-friendly operation.. The DOGSE is highly compact and very low mass making it suited for both open- and closed-loop star tracker tests. The DOGSE can be adopted to fit any baffle, providing repeatable and stable mounting required for closed loop testing.
DOGSE Data Sheet

HERITAGE

With 25 years of experience in star tracker technology, Terma has established itself as a leader in providing reliable equipment. Our star trackers consistently deliver precise navigational data, earning their status as trustworthy tools in the space industry.
